Manual Glass Drilling Machine A11B, equipped with a numerical control operating system (a console with a touch screen and operation buttons) and adopts a universal wheel and roller conveying platform design. It realizes the flexible conveying and precise positioning of glass through a large number of universal wheels and roller.
1：This device is designed for standalone use, with automatic positioning and manual movement of the glass to the positioning block;
2：The operating interface of this device is an industrial computer and can be used for online drawing;
3：Can match barcode scanner, read QR codes and barcodes, and connect to factory ERP;
4：Can install two different diameters of drill bits; The minimum center distance between two drill bits is 170mm, but they cannot be machined simultaneously;
5：The platform is composed of 304 stainless steel pipes, universal wheels, and rubber rollers;
|
Processing range |
X1:0-1500mm; X2:0-750mm;Y1:0-1100mm |
|
Drilling diameter |
Φ6-Φ50mm |
|
Glass thickness |
4-19mm |
|
The speed of screw propulsion |
0-3mm/s |
|
Overall size |
4380*2800*1600mm |
|
The height of the table |
900+/-20mm |
